· Высокая контрастность изображения
· Высокая однородность яркости
· Подходит для сенсора 2,4U, разрешение до 10 МП
· Компактный, легкий и прочный
| Объектив Taurus Series 1 ″ формата FA ( 10 МП) |
|||
| Модель |
UN-TFA1220L -10MP |
||
| Фокусное расстояние |
12 мм |
|
|
| Диафрагма |
Ф2.0-Ф22 |
||
| Формат изображения |
1 дюйм (16 мм) |
||
| Устанавливать |
С |
||
|
Угол поля
|
|
Г x В x В (°) |
|
| 1" |
67,6°×56,7°×43,5° |
||
| 1/2 дюйма |
36,17°×30,1°×23,13° |
||
| 1/3" |
27,78°×23,14°×16,97° |
||
| Оптические искажения |
<-0,8% |
||
| МОД |
0,1 м |
||
| Измерение |
Φ41*62,6 мм |
||
| Фланец БФЛ |
1 7 . 5 26 мм |
||
| Заднее фокусное расстояние _ _ |
10,5 мм |
||
| Операция |
Ручная ирис |
||
| Ручная фокусировка |
|||
| Расчетная длина волны |
420~1000нм |
||
| Фильтр Резьба |
М37,5×П0,5 |
||
| |
|||
